6 Output Channel Disgistal Multi-Functional TENS Body Massager Electric Muscle Stimulator Relax Electroacupuncture Patch Massage
Packing Including:
1pcs Charger
1pcs Instriction Book
1pcs Main Engine
6pcs Electrode Pad
6pcs Electrode Line
12pcs Metal Electroacupuncture Clamps
Specification:
Product Name : Electronic Acupuncture Therapeutic Instrument DMZ
Volume : 240×177×64mm
Weight : 1.1kg
Output Voltage : No More Than 500V (Operating Load 250Ω)
Input Power : DC 9V is 0.8VA; AC / DC converter is 5VA
Effective Value of Maximum Output Current : No More Than 10mA
Rated Load Impedance of Electroacupuncture Apparatus :
A) the patch electrode is 5009;
B) the electrode clamp is 250 Ω.
Precautions for use
Not for use on patients with implanted medical devices such as pacemakers.
Using electrodes close to the chest increases the risk of fibrillation.
It cannot be used for pregnant women, patients with acute diseases, infectious diseases, malignant tumors and heart diseases.
Electroacupuncture should not be performed on scars, scars and inflamed skin.
Do not use while driving or operating machinery.
Do not use while bathing and sweating.
When starting the treatment, the two filiform needle electrode clips or skin electrodes at the output end of the same group should not touch each other, so as to avoid short circuit and damage to the instrument.
Disposable acupuncture needles or skin electrodes are recommended to avoid cross infection.
Contact with metal objects is not allowed during use.
Do not attach skin electrodes to the eyes, the front of the neck, and the heart.
Do not use in flammable and explosive gas situations.
Keep a certain distance from TVs, radios and other electrical equipment to avoid possible electromagnetic interference.
Acupuncture needle treatment should be used by a professional doctor (acupuncture needles are not part of this product). When the acupuncture needles are bent and deformed, the surface is oxidized, rusted, or stained, it cannot be applied.
When used for measurement of load resistance exceeding ±10%, the deviation of pulse repetition frequency and degree value, including any DC component, during pulse duration is not more than 30%.
The influence of the power supply voltage fluctuation ±10% on the output amplitude, pulse duration or pulse repetition frequency of the instrument is not more than ±10%.
