Low-Frequency Electro Acupuncture Stimulator Hwato SDZ III 6 Channels Acupuncture Needle Treatment for Nerve and Muscle Massage Relaxation
Features:
1, large screen display: check the parameter information more intuitive, accurate, mode, frequency, time, the information such as output state be clear at a glance.
2, operation more convenient, flexible:
mode button, frequency knob, time knobs are integrated into one key, the operating interface is simple, it is more convenient to use.
3, boot from Settings, directly open the treatment:
Instrument after startup, output channel is closed, long press shuttle 3 seconds, restore the default parameters automatically.
4, parameters memory function:
Automatically save the last treatment parameters, boot can directly open to treat next time.
5, the sleep function, the use of more economy：
Through the sleep function, can save 25% of the electricity, instrument after startup, output channel is closed, more than 3 minutes without any operation, the instrument will automatically enter the sleep state, the LCD screen automatically extinguished.Operate shuttle key can awaken the instrument, the LCD screen light up automatically.
Specifications:
1, the power supply: the internal power supply DC9V, power adapter input, 220 v / 50 hz output DC9V / 150 ma
2, the input power: 10.0 VA
3, the output pulse shape, asymmetric bidirectional pulse wave
4, the output pulse way: output
5, the maximum pulse power: 0.3 VA (250 Ω load)
6, the output pulse frequency: 1 ~ 100 hz is adjustable
Working pattern:
Continuous wave work modes: continuous
Discontinuous wave work modes: 15 s, 5 s
Dilatational wave work mode: thin wave frequency and the ratio of the dense wave frequency is 1:5, thin wave 5 s work, 10 s
Output current limit: less than or equal to 10 ma, 250 Ω load)
Output dc component: 0
Size: 210 mm * 100 mm * 300 mm
Weight: 1.6 kg (including battery)
Package Included:
The host * 1
Output wire * 6
Needle electrode metal clip * 6 pair
Skin electrodes * 6 pairs
The power adapter * 1
Manual * 1
