6 Output Channel TENS Body Massager Tennis Electroestimulador Muscular Electric Muscle Stimulator Physical Therapy Masajeador
Specification
Product Name: Electronic Acupuncture Therapy Instrument (6 Output Channel )
Output voltage peak: not more than 500V (250Q load)
Input power: 0.8VA for DC 9V; 5VA for AC/DC converter
Maximum output current RMS: no more than 10mA
Rated load impedance of the electroacupuncture instrument: a) 500Q for patch electrodes; b) 250Q2 for milli-needle electrode clips
Features
*1. Six outputs, can massage 12 acupuncture points at the same time.
*2. Dual power supply mode, plug-in/battery use (requires 6 C Batteries, not included in this product).
*3. Three waveforms: continuous wave/interrupted wave/popping wave.
*4. Adjustable pulse width: 30-200 microseconds adjustable range.
*5. Adjustable intensity frequency: continuous 1-99Hz pulse frequency.
*6. Digital timing: intelligent chip control, automatic timing treatment.
Three Therapeutic Waveforms
*Continuous wave frequency: 1-100Hz continuously adjustable.
*Intermittent wave frequency: 1-100Hz continuously adjustable, intermittent wave time is 10 seconds, continuous wave time is 30 seconds.
*Sparse and dense wave frequency: 1/5 of dense wave frequency, dense wave frequency is adjustable from 5-100Hz, sparse wave time is 10 seconds, dense wave time is 15 seconds.
Translated with www.DeepL.com/Translator (free version)
Adjustable pulse width
Pulse Width:30-200 uS adjustable
Frequency: 5-99hz adjustable
Adjustable pulse width for extensive clinical data selection
High precision LCD display, intelligent chip control, automatic timer treatment.
Electrode sheets for physiotherapy
Self-adhesive electrode sheets are required to remove the transparent film before use and then reapply it after use for recycling.
F1 - Continuous waves
F2 --- Intermittent waves
F3 --- Sparse and dense waves
Two power supply modes
No.1 Power cord supply
No.2 C battery*6
(Note: No batteries are supplied with this product!)
Packing Including:
1pcs*Main Machine
6pcs*Electrode Line
6pcs*Electrode Pad
6pcs*Metal electric needle clips
1pcs*Charger
1pcs*Manual
How to use
(It is best to wipe the area to be treated with a hot towel or medical alcohol before use. All intensity adjustment knobs must be returned to 0 before switching on the output, otherwise the alarm will indicate that it cannot work.)
① Preparation
1) Insert the output cable into the jack of the skin electrode; peel off the anti-adhesive paper on the skin electrode and stick it to the part to be treated, insert the other end of the electrode output cable into the output jack, the treatment should be finished by pulling out the output cable plug from the jack first, then remove the skin electrode.
2) If using electro-acupuncture treatment, insert the electrode output cord into the milli-needle electrode clip and then clip the milli-needle electrode clip onto the shank of the acupuncture needle that has been acupunctured. When using electro-acupuncture, it must be used by a professional acupuncturist and operated in strict accordance with the electro-acupuncture protocol.
Turn on the machine
1) Press the power switch and wait for the power display light to come on.
2) Check and adjust the six output intensity adjustment knobs, all to the left to zero (otherwise it will cause an alarm sound) choose to press the Mo is button (continuous wave, intermittent wave, sparse and dense wave three modes).
③ Setting
1) press the mode button, you can choose continuous wave, intermittent wave and sparse wave three waveforms; timing time for 1-60min continuously adjustable, according to the desired treatment time adjustment button, you can set the instrument's treatment time.
2) The pulse frequency of the electro-acupuncture instrument is continuously adjustable from 1 to 99Hz, set the frequency according to the desired treatment frequency adjustment button.
④Shutdown
1) Turn the intensity adjustment knob off counterclockwise. Turn off the power switch of the instrument.
2) Remove the needle body or skin electrode and unplug the output electrode cable. Remove the external power supply.
